Lawmate PV-RC400UW is a new 4K Ultra HD mini DVR with
an integrated W-Fi module in a covert keyfob design.
This is a better and upgraded version of LawMate's bestselling PV-RC200HDW with 4K Ultra HD video
quality and larger storage. Thanks to its Wi-Fi connection, the PV-RC400UW can
be easily connected to your smartphone app and controlled via your smartphone.
Due to its completely covert design, it is popular
among professionals for collecting evidence on the go. It is user-friendly and
easily operated.
PV-RC400UW Main Features:
- 4K Ultra HD video quality
- 1/2.8" Progressive CMOS Sensor
- Built-in Wi-Fi Module
- Manual and Motion Detection recording modes
- Records at 25, 30, 60, and 120 fps
- It takes up to 256 GB memory cards
- Overwrite recording function
PV-RC400UW Full Specifications:
Built-in Image Sensor: 1/2.8" Progressive CMOS Sensor
Sensor Resolution: 2592 × 1944
Sensor Sensitivity: 2.8 Lux @ F 3.2
Lens F/No.: F 3.2
Focal Length: 4mm
The angle of View: 66°
Algorithm: H.264, JPEG
File Format: MOV, JPG
Video Recording Mode: Manual & Motion Detection
Recording Capability: 3840 × 2160@25/30fps; 2704 ×
1520@30fps; 1920 × 1080@30/60/120fps; 1280 × 720@60/120fps
Frame Rate: 25 fps, 30 fps, 60 fps, 120 fps
Wi-Fi: Built-in Wi-Fi Module(IEEE 802.11b/g/n)
Wi-Fi Protocol: RTSP
Memory Type: Micro SD Card ( Support SDHC max = 256GB)
Data Interface: Mini USB 2.0
Date/Time Table: YYYY/MM/DD, HH:MM:SS
Snapshot: Recording and playback video (Via APP), Size
4320 × 3240
Power Input: DC 5V
Power Consumption: 350mA (Wi-Fi OFF) (Wi-Fi ON +
100mA)
Charging Frequency: 300mA
Battery Input: DC 3.7V / 660mAH high polymers battery
Battery Lifetime: Continuous Recording 75min (Wi-Fi
ON) / 110min (Wi-Fi OFF)
Recording Time: 140min @ 3840×2160@30fps resolution
(64GB SDHC card)
Vibration Alert: Power on/off, Recording, Low Battery
Dimension: 70 × 40 × 15mm
Weight: 46g
PV-RC400UW Feature Focus:
LawMate 4K Ultra HD Video Quality
PV-RC400UW is the first LawMate DVR camera in 4K
resolution. This is the resolution of 3840 x 2160 pixels which results in
clearer and more detailed images that are capable of displaying more
information at once. This standard is widely used in media, television
broadcasts, and now in the security industry as an important factor for
professionals when collecting video evidence in ongoing investigations.
Built-in WiFi module in covert keyfob DVR design
LawMate PV-RC400UW has a built-in Wi-Fi module that
allows you to connect your keyfob camera to your smartphone and via the
smartphone app you can have full control of your Lawmate keyfob camera. You can
change the settings, start and stop recordings, set time and date, and operate
other features. Thanks to the Wi-Fi button you can deactivate WiFi options so
all recordings are stored on a complimentary SD card in which case the keyfob
camera is operated by pressing buttons on the device itself.
Capturing videos in frame rates up to 120 fps
Various frame rates provide greater flexibility in
post-production and with the advance of technology, the need for higher frame
rates grows. The options of capturing videos in 25, 30, 60, and 120 fps give
you the flexibility to capture the best video for your particular needs –
whether you are an investigative journalist or private detective.
Large SD Card storage available
This keyfob camera comes with a lower-capacity SD card
for storing data but it is also compatible with larger-capacity SD cards with a
maximum of 256 GB. The larger capacity is for some clients crucial when it
comes to collecting a large amount of data. This is a new feature that is
now available in this latest LawMate kefob camera.
PV-CAM
iOS and Android apps for LawMate Wi-Fi recorders:
PV-RC400UW 4K Keyfob Wi-Fi DVR FAQs
Can I control the RC400UW remotely?Yes, the RC400UW supports remote control through Wi-Fi from both Android and iOS devices. This is achieved by linking the device with the PV-CAM app, allowing users to view live video streams, modify settings, and manage the device within Wi-Fi range. Such functionality improves the device’s versatility for discreet surveillance or observation tasks without requiring direct access to the DVR.
Does the PV-RC400UW 4K support audio recording?All LawMate DVRs, including the PV-RC400UW 4K, record audio along with video. This feature allows for comprehensive surveillance that captures both visual and auditory elements of the environment being monitored. Audio recording adds an extra layer of detail to the surveillance footage, making it more informative.
How do I set up the time/stamp and firmware on the PV-RC400UW 4K?Configuring the time/date stamp and updating the firmware on the PV-RC400UW 4K is simplified through its Wi-Fi connectivity and app-based interface. Through the PV-CAM app, users can smoothly update the device’s firmware, adjust or sync the time/date stamp, or even disable it entirely, making the process of managing and personalizing the device straightforward.
How do I start using the PV-RC400UW 4K?To start using the PV-RC400UW 4K, open the backside, insert an SD card, press the power on/record button to turn on the device, and if desired, press the power on/record button again to start recording. To enable Wi-Fi, press the Wi-Fi on/off button, connect your mobile device to the " PV-RC400UW 4K…” network using the initial password "88888888”, and use the PV-CAM app for live monitoring.
How long can the PV-RC400UW 4K record on a single charge?The PV-RC400UW 4K can record up to 140 minutes at 2160p resolution(4K) on a single charge. Its energy-efficient design allows for extended recording times, making it suitable for longer surveillance operations without the need for frequent recharging. This feature is particularly useful for capturing extended footage without interruption.
Is the PV-RC400UW suitable for covert operations?Yes, the PV-RC400UW 4K is designed for covert operations with its ordinary car key fob appearance. This discreet design allows it to blend in with everyday items, making it ideal for surveillance without attracting unwanted attention. Its covert nature is enhanced by vibration alerts and LED indicators for stealthy operation.
What happens if the SD card is removed from the PV-RC400UW?The PV-RC400UW has an automatic off mode that activates when the SD card is removed. This feature prevents accidental battery drainage by ensuring the device turns off if the storage medium is removed, thereby conserving battery life and ensuring the device is ready for use when needed.
What is the video resolution of the LawMate PV-RC400UW 4K Keyfob DVR?The LawMate PV-RC400UW records in 4K 2160p resolution. This high-quality video recording ensures clear and detailed footage, suitable for various surveillance needs. The device uses a 5MP CMOS sensor to capture video, providing users with sharp and high-definition video recordings.
Where can I find the PV-CAM app for the PV-RC400UW?The PV-CAM app for the PV-RC400UW can be found on
Google Play and the
App Store. The app enables users to connect to the PV-RC400UW for live video monitoring and device control.
Note:
For more details on setting up and usage of the
device, please study the PDF files below.
24 months warranty.
