The LawMate CM-EP10 Earphone Type CCD Camera is the perfect covert device for the 21. century user
No one pays attention to people who listen to music on their MP3s, iPods, or smartphones anymore.
CM-EP10 Product Features:
- Miniature Earphone Concealed Outlook for Covert Surveillance Application Use
- High Resolution & Low Power Consumption CMOS Sensor Selectable for Various Demand Applications
- Complete Power & Cable Accessories Attached to Offer Output to More variety of Device Use
- Full Range of our Wireless Kit & Recording Device Could be Obtained & Worked with Optionally
- Standard Audio & Video Analog Output Protocol Allows to Work With any Regular AV Device Instantly
Full Specifications:
Item Number: CM-EP10
Video System: NTSC & PAL
Picture Element: 640 x 480
Resolution (H): 480 TV Lines
Image Sensor: CMOS 1/4 inch
S/N Ratio: 50 dB
MIN Illumination: 3 Lux / 30 IRE @ F2.0
Video Output: 1.0V p-p Composite at 75 ohm
Audio Output: 2Vp-p(MAX) 10KHz ohms Impedance
MIC Sensitivity: Yes
Lens: 3.59 mm
Angle of View: 66.5 Degrees
Power Supply Voltage: DC 5V
Power Supply Current: 130 mA
Operation Tempareture: -10~50
Storage Temperature: -10~50
Dimensions (Incld Lens): 23(W)x26(H)x18(T) mm
Weight: 25 g
CM-EP10 How To Illustration (from the quick manual):
How to use CM-EP10?
- Connect the earphones to a portable DVR
- Turn on the DVR
- Make sure that the plugs are placed so the wire does not fall vertically from your ears
- Keep in mind that the position of the camera will be from your ears outwards
- Start recording
Is this product discontinued?Yes, the LawMate CM-EP10 is discontinued and no longer in stock. We recommend the LawMate CM-NL10 Necklace Camera as replacements.
How is the camera concealed?
It's built into the design of an earphone, so it blends in naturally with people listening to music on an MP3 player, iPod, or smartphone — making it a discreet covert device.
Which DVR works best with it?
It's compatible with various LawMate DVRs, but for the best fit, the LawMate PV-900HD Cellphone DVR camera is recommended.
What resolution and low-light performance does it offer?
It records at 480 TV Lines resolution with a minimum illumination of 3 Lux / 30 IRE @ F2.0, using a 1/4 inch CMOS sensor.
Which recording devices is it compatible with?
It works with the LawMate PV-500L3 (Standalone), PV-500L3 w/ Q-CM-BU18 Cam, PV-500 EVO2U DVR, PV-BX12 Box DVR w/PIR, and PV-1000Touch5U 500GB DVR.
Notes:
The Lawmate CM-EP10 Earphone Type CCD Camera is compatible with Lawmate's:
Lawmate PV-500L3 (Standalone)
Lawmate PV-500L3 w/ Q-CM-BU18 Cam
Lawmate PV-BX12 Box DVR w/PIR
Lawmate PV-1000Touch5U 500GB DVR
For further details regarding the Lawmate CM-EP10 earphones please consult the PDF guide below.
24 months warranty.
