The PV-900 EVO3 offers a Full HD resolution and multiple FPS option; 25 /30 /60. It has an 64 GB integrated memory and can record in Auto/Manual/Motion detection modes.
The Wi-Fi DVR can be connected to your Smartphone, and the live feed can be monitored, downloaded or set up via the App. Snapshots are available with a 5M(2592*1944) photo resolution.
It has a instant record key to start recording 3 seconds upon powering up. It also comes with multi-layered password protection and the option to disguise the screen to look like it is off or to display the password lock interface.
It has a recording time of 230 minutes when the Wi-Fi is powered off, and 180 min of recording time in Wi-Fi mode.
The timestamp option is available.
PV-900 EVO3 Full Specifications:
LCD: 5" 854 x 480 TFT-LCD
Built-in Image Sensor: 1/3" progressive CMOS sensor
Sensor Resolution: 2304x1536
Sensor Sensitivity: 3.3 Lux @ F 2.0
Lens F/No.: F 3.2
Focal Length: 4mm
Angle of View: 66°
Algorithm: H.264, JPEG
File Format: MOV, JPG
Video Recording Mode: Auto/Manual/Motion Detection
Recording Capability: 1920x1080, 1280x720, 640x480
Frame Rate: Up to 60 fps (25fps/30fps/60fps)
Photo Capability: 5M(2592*1944)
Memory Type: Built-in memory: 64G Module
Data Interface: Mini USB 2.0
Disguised Mode: Stand-By, LCD-Oﬀ
Date/Time Table: YYYY/MM/DD, HH:MM:SS
Power Input: DC5V
Power Consumption: 710mA(Wi-Fi oﬀ)-850mA(Wi-Fi on) LCD ON
Battery Input: DC 3.7V / 2000 mA Lithium battery
Charging Time: 240min(700mA)
Battery Lifetime: Continue recording 230min (Wi-Fi oﬀ)-180min(Wi-Fi on)
Vibration Alert: Power on/oﬀ, Recording, Photo, Low battery
PV-900EVO3 Frame Rate Options - 25 / 30 / 60 FPS
PV-900 EVO3 Feature Focus
Multiple resolution, FPS and recording optionsThe device allows for precise configuration of video recording modes (Auto/Manual/Motion Detection), recording resolutions (1920x1080, 1280x720, 640x480), and Frames per Second (25fps/30fps/60fps).
There are two ways of locking the screen / disguise recording
The first allows you to record and not accidentally stop because of touching the LCD etc. And the second one looks like a classic lock interface that requires a password or a pattern to unlock the phone;
- Password Lock Interface
- Screen Display Off
Multi-layered password protection optionYou can set up a login password so that your device and the content of your media files are protected.
Audio On/OffChoose whether to record the audio or not, depending on your surveillance needs.
PV-CAM iOS and Android apps for Lawmate Wi-Fi recorders:
Google play link:
App Store link:
How to use the PV-900EVO3 DVR:
- Press the Power On/Off button
- Select Motion Detection or Normal recording mode, and press REC on the screen to start recording. You can also start recording automatically via the instant record switch on the phone.
- To connect to Wi-Fi enable the Wi-Fi switch on the DVR. Connect the device to your smartphone and launch it in the PV Cam viewer App. For more info take a look in the PV Cam Guide for Wi-Fi Cams available for download below.
PDF specifications and Wi-Fi setup guide available for download below.
Warranty 24 Months
