The LawMate PV-500HDW Pro has all the features and advantages of the PV-500HDW but comes with a 3' LCD screen that offers additional usage options.
This product is end of line and no longer available. If you are looking for a product with the same or similar specifications, please see related products at the end of the page or contact us directly at [email protected]
This DVR has quite a few possibilities for monitoring and operation of the device. It can be operated manually, on the DVR, or via the cable controller that comes with the accessories.
When connected to a Wi-Fi network via your Android or iOS device, it can be remotely controlled, set-up, and you can view your videos or download them.
Now the PI-RF50TX
has been released - a cable controller that allows you to control the DVR form up to 10 meters away.
All these options will take your work and ease of operation to a whole new level. It also offers the possibility of multiple persons working with one device at the same time.
PV-500HDW Pro Main Features:
- 3' Touch Screen
- Full HD 1080p @30FPS
- Wi-Fi enabled DVR
- Records up to 160 minutes in 1080p with BA-2200
- Compatible with the BA-4400
- Compatible with the PI-RF50TX cable controller - control without touching the DVR
- Connect it to any Wi-Fi enabled Android/iOS device via the DVR's App
- Monitor your video feed and/or download the material from your Android/iOS device
- Record video and take snapshots from your Android/iOS device
- Cannot turn on when SD card is removed (prevents battery loss)
- LED indicators to easily recognize the various modes and functions of the Wi-Fi DVR
PV-500HDW Pro Full Specifications:
Video Input: BU-18HD (2000*1121) CMOS Camera
Compression Algorithm: H.264, JPEG
File Format: MOV, JPG
Video Recording mode: Auto/Manual/Motion Detection/Overwrite
Recording Resolution:: 1080P/720P/WVGA
Frame Rate: Up to 30fps
Wi-Fi: Built-in Wi-Fi Module (IEEE 802.11b/g/n)
Memory type: Micro SD Card (up to 32GB SDHC)
Data interface: Mini USB 2.0
Date/Time Table: YYYY/MM/DD, HH:MM:SS
Power Input: DC 5V
Power Consumption: 380mA-440mA
Battery Lifetime: 160min @1080P Resolution with BA-2200
Dimensions: 85*54*21mm (With Battery)
Weight: 104g (With Battery)
*Names and Parts from Quick Manual
PV-500HDW Pro Feature Focus:
Built-in Wi-Fi Module - once you establish a connection between your smartphone and the PV-500HDW Pro, you can remotely change the settings of the device, such as motion detection and resolution. Also, you can monitor the live feed, take snapshots, or download the material.
3' Touch Screen - although the device has the option to monitor the live feed via your smartphone, a great number of requests have been placed for an LCD screen to the PV-500HDW. This is the new version, featuring a 3' LCD screen that opens quite a few possibilities depending on the type of work you do. For starters it offers the possibility to be used by multiple persons, one monitoring the screen and the other the live feed via the smartphone.
Compatible with the PI-RF50TX cable controller - control without touching the DVR and operate the HDW Pro from up to 10 meters away. The controls follow Lawmate's known user experience - with the - Power/Wi-Fi/Record button - design.
PV-CAM iOS and Android apps for LawMate Wi-Fi recorders:
Google play link:
App Store link:
How to start recording with the PV-500HDW Pro:
- Connect the camera to the mini USB camera jack of the DVR
- Make sure the SD card is inserted, and the battery is charged
- Press the power button for 3 seconds
- Press the record button if you wish to start/stop recording before connecting the DVR to Wi-Fi
- Press the power button for the second time to turn on Wi-Fi
- Connect your Android/iOS device to a Wi-Fi Network that starts with "PV-500 HDW.."
- Use the default password "88888888" - it can be changed later on in the App Settings
- Open your PV-CAM app and start monitoring your live feed
For a step by step guide through all the functions of the device, please carefully study the PDF files below.
24 Months Warranty
Note you can lock/unlock the screen by long-pressing the "Rec" button.
>>Download detailed specifications (PDF)<<
