The Pixel
Nano 4G Spy Bug is designed to address a need in the surveillance market for
advanced and high-quality listening devices able to operate on modern 4G
networks.
This compact
and lightweight stand-alone listening audio device with an integrated LI-ion
battery and high-quality Knowles microphone can be easily installed in a
variety of settings like cars, rooms, offices, and other places where crystal
clear sound is crucial for completing the mission. Its mini external power
supply unit with AC input power (110-220 Vac) makes installation in various
places quick and easy while an integrated battery allows it to even be body
worn.
Pixel Nano
4G is simply programmable via SMS and offers an automatic call-back option with
VOX/VAS or motion events. The setup is easy and done by sending an SMS to the
number on the SIM card inside the Pixel Nano 4G. To ensure maximum protection,
the setup and calls are protected by a password.
In terms of
technical specifications, the Pixel Nano 4G operates on quad-band 850/900/1800/1900
MHz, 4G-FDD Band 1/2/3/5/7/8/20, 4G-TDD Band 38/39/40/41, and 2G-GSM Band
2/3/5/8. It features a sensitive GSM patch antenna, Knowles microphone (also
available in a waterproof version), and a 5V-2000mAh Li-Ion battery that can be
recharged via micro-USB plug or external PSU with AC input power (110-220Vac).
The unit is highly customizable with low power consumption in standby mode and
operates on a 4G GSM network (and 2G in the absence of 4G coverage).
Pixel Nano 4G Main Features:
• Operates on 4G GSM Network (and 2G in the absence of 4G coverage)
• Small in size and lightweight ( 63 x 43 x 13 mm/ 50g)
• Automatic callback function triggered by VOX/VAS or motion events
• High-quality audio transmission
• Low power consumption in standby mode
• Mini-external PSU with AC input power (110-220Vac) and integrated Li-Ion rechargeable battery for standalone operations
Pixel Nano 4G Full Specifications:
Frequencies: Quad band 850/900/1800/1900 Mhz ; 4G-FDD: Band 1/2/3/5/7/8/20; 4G-TDD: Band 38/39/40/41 ; 2G-GSM: Band 2/3/5/8; GSM - Patch antenna
Sim-card: Nano – Sim (Standard 4FF)
Sensibility GSM: <- 106 dBm (typ.)
Microphone: Knowles (available also in water proof version)
Power supply: 5V - 2000mAh Li-Ion battery rechargeable / Micro-USB plug to recharge the battery / 7-28 Vdc (DC-DC adapter) / 110-220Vac (AC-DC ext. PSU)
Consumptions: 10-14 mA in sleep mode, 120-140 mA in live mode
Dimensions: 63 x 43 x 13 mm (heat shrink) 50 g
Feature Focus:
4G GSM Spy Bug
Due to the closure of 2G networks in many countries around the world, which are commonly used by spy bugs, there has been an increased demand among our clients for a 4G spy bug. The Pixel Nano 4G is designed to operate on the 4G GSM network and can also switch to 2G when 4G coverage is not available.
Quick and easy installation in vehicles, offices, and rooms
Thanks to its integrated rechargeable Li-Ion battery and additional mini external power supply unit with AC input power (110-220Vac), the Pixel Nano 4G can easily be installed in a variety of surroundings like indoor places or even cars so it can be quickly transformed into a car bug. This 4G spy bug can also be worn and used in many different undercover missions.
SMS configuration, call back, and shock-sensor function
To configure the Pixel Nano 4G Spy Bug, you can send an SMS to the phone number associated with the SIM card inside the device. For security reasons during covert operations, these messages are password-protected. This 4G spy bug includes a call-back function that automatically dials the administrator's number when a sound is detected. Additionally, the device offers a shock sensor recall feature that calls the administrator's number as soon as any movement is detected.
High-quality sound
The on-board DSP (digital signal processing) ensures clear audio quality, making the Pixel Nano 4G an excellent choice for intelligence missions that require high-quality audio surveillance. Additionally, the device comes equipped with a Knowles microphone, which is available in a waterproof version as well.
How to use the Pixel Nano 4G:
1. Insert the SIM card into the Pixel
Nano 4G and make sure the PIN, call transfers, and other answering services are
disabled. Make sure there is enough credit on the SIM card if using a prepaid
SIM card.
2. After inserting the SIM card press
the power button for at least 7 seconds and follow the led lights that will
appear as described in the manal
Note:
For more
details on setting up and usage of the device, please study the PDF file below.
24 months warranty.
